Technical Details
PRODUCT SPECIFICATIONS STANDARD TWINE+LOCK
• Product standard: EN 15114 Woven vinyl flooring
• Total thickness: EN ISO 24346 – 5.0 mm
• Classification: EN ISO 10874 – Domestic: 23 / Commercial: 33 / Industrial: 42
• Total weight: EN ISO 23997 – 7,890 g/m²
• Dimensions: EN ISO 24342
• Tiles: 457.2 x 457.2 mm
• 10 tiles/box = 2.09 m²
• 52 boxes/pallet = 108.68 m²
• Surface treatment: PUR Ecoprotec™
• Locking system: Interlocking
• Bevelled edges: No
• Fraying: EN 1814 – Frayproof
PRODUCT PERFORMANCES STANDARD TWINE+LOCK
• Dimensional stability: EN ISO 23999 – ≤ 0.10%
• Castor chair resistance: ISO 4918 – No damage (Type W)
• Furniture leg resistance: EN ISO 16581 – No damage
• Squareness & straightness: EN ISO 24342 – ≤ 0.25 mm
• Residual indentation: EN ISO 24343-1 – ≤ 0.10 mm
• Impact sound reduction: EN ISO 717-2 – ΔLw = 9 dB
• Light fastness: EN ISO 105-B02 – ≥ 6
• Slip resistance: DIN 51130 / EN 13893 – R11 / DS
• Chemical resistance: EN ISO 26987 – Not affected (0)
• Thermal resistance: EN ISO 10456 – 0.04 m² K/W
• Curl after heat exposure: EN ISO 23999 – ≤ 2 mm
• Fire resistance: EN 13501-1 – Bfl-s1
• Electrical properties: EN 1815 – ≤ 2kV
• Stain resistance: EN 26987 – Passed
• Underfloor heating suitability: EN 12524 – Suitable (max. 27°C)
ENVIRONMENT STANDARD TWINE+LOCK
• TVOC after 28 days (AgBB test): ISO 16000-9 – ≤ 100 µg/m³
• VOC emission class (French regulation): ISO 16000-9 – A+
• Floorscore VOC test: ISO 16000-9 – Passed
• Plasticizer: Phthalate-free
• Formaldehyde group: EN 717-1 – E1
• Recyclability: 100%
WARRANTIES STANDARD TWINE+LOCK
• Residential warranty: 25 years
• Commercial warranty: 10 years
CE MARKING STANDARD TWINE+LOCK
• DoP number: No. TWINE+LOCK_001
