Technical Details
Construction Tufted, Textured Tip Shear
Face Fibre ECONYL® Solution Dyed 100% recycled Nylon
Stain Resist Inherently stain resistant fibre
Finished Face Weight 570 g/m2
Gauge 47.2 / 10 cm
Rows 44 / 10 cm
Tuft Density 207,874 /m2
Finished Pile Height 2.9 mm
Standard Backing WellBAC® Comfort 90% recycled open cell polyurethane cushion backing
Available with TractionBack® on request
Nominal Total Thickness 9.4 mm
Tile Size 50 cm x 50 cm
Nominal Total Weight 3900 g/m2
Tiles per Box 20 (5M)
Design Copyright – Milliken & Company. This cushion-back carpet tile product is covered by one or more patents, published applications and/or patents pending.
Specifications are subject to normal manufacturing tolerances and may be changed without prior notice. Copies of actual test results are available upon request.
SPECIFICATION SHEET Date: 26.02.2024 Revision 14
INSTALLATION
Brick
PERFORMANCE
Flammability (Euroclassification EN13501:1-2018) Class Bfl – s1
Flammability (Radiant Panel ASTM-E-648) Class 1
Flammability (Hot Metal Nut BS4790) Low Radius of Char
Use Classification (EN 1307) Class 33 Heavy Commercial Use
Castor Chair (BS EN 985:2001) Class A – Intensive use (r value ? 2.4)
Static Electricity (ISO 6356) Pass ? 2.0 KV Permanent Conductive Fibre
Impact Sound (ISO 10140-3) 33 dB ?Lw
Sound Absorption (ISO354) 0.30 (H) Class D
Alpha p values 125Hz 0.00, 250Hz 0.05, 500Hz 0.30, 1000Hz 0.25, 2000Hz 0.30, 4000Hz 0.35
WARRANTIES
12 year wear warranty
Lifetime Antistatic guarantee
Latent Defects guarantee
